COBALT LITHIUM MANGANESE NICKEL OXIDE (NCM) CAS 346417-97-8/182442-95-1
Identification
Properties
Safety Data
Specifications & Other Information
Links
Identification
CAS Number
346417-97-8/182442-95-1
Name
COBALT LITHIUM MANGANESE NICKEL OXIDE (NCM)
Properties
Appearance
Black solid powder
Safety Data
Symbol
GHS07, GHS08Signal Word
Warning
Hazard Statements
Precautionary Statements
RIDADR
NONH for all modes of transport
WGK Germany
3
Specifications and Other Information of Our COBALT LITHIUM MANGANESE NICKEL OXIDE (NCM) CAS 346417-97-8/182442-95-1
Standard
Enterprise standard
The First C-D effciency
≥85%
Discharge Capacity/(mAh/g, vs.Li)
160～170(2.75～4.3V, vs.Li)
Specific Optical Rotation
+31.0-+35.0°
Compacted Density/(g/cm3)
3.6～3.9g/cm3
Cycle Life
>85%
Detailed Specification
| Item | Unit | SPEC | |||
| Product Property | Physical properties | PSD | D50 | µm | 11.50±2.00 |
| D10 | ≥2.0 | ||||
| D90 | ≤25 | ||||
| Dmin | ≥2.0 | ||||
| Dmax | ≤35 | ||||
| BET | m2/g | 0.2-0.5 | |||
| Tap Density | g/cm3 | ≥2.2 | |||
| Chemical properties | Li2CO3 | ppm | ≤2000 | ||
| LiOH | ≤2000 | ||||
| Impurities | Fe | ppm | ≤80 | ||
| Cu | ≤50 | ||||
| Zn | ≤50 | ||||
| Ca | ≤50 | ||||
| Na | ≤200 | ||||
| Mg | ≤200 | ||||
| Magnetic Impurities | ppb | ≤100 | |||
| pH | – | 11.20±0.5 | |||
| Moisture | ppm | ≤500 | |||
Storage
Under the room temperature and away from light
Application
High capacity and long cycle life lithium nickel-manganese-cobalt oxide (NMC), mainly used in Power bank/ NB/ PT Batteries.
